Parameters
| Production capacity | 1000 – 5000pcs/h |
| Pizza size | 15cm-38cm |
| Belt width | 420mm – 1300mm |
| Dough width | 400mm-1280mm |
| Dough thickness | 2mm-15mm |
| Proofing time | 10-22mins |
| Baking time | 2.5-3mins |
| Baking temperature | 350-400℃ |
| Cooling time | 25mins, tailored |
| Dough mixer | Removable bowl type |
| Hopper volume | ＜200kg/time |
| Hopper height | 2.1m |
Features
- The thickness of the dough band coming out from all the pressing equipment can be adjusted through PLC, which can be saved in the product formula.
- The whole line can realize single machine speed regulation and overall speed regulation.
- The equipment is equipped with a remote control module, which can be connected to the network for the user to check the operation status of the line.
- Camera monitoring devices are installed at the dough input, proffer, and forming line with a set of monitoring screens to quickly observe the operating conditions of each link.
- Each machine unit has a cover plate that can be opened quickly for easy cleaning.
- Each transmission and connection link of the line are equipped with scrapers and dough scrap collection boxes to keep the equipment and the ground clean.
Main Machine Units
These typical cutters enable the line to produce pizzas in round, square, rectangular and pizzas with thick crust to meet clients’ request.
-
Cutting PartRotary cutter
-
Cutting PartLongitudinal cutter
-
Cutting PartStamping cutter
-
Proffer / Fermentation room
As we all know, Fermentation/proofing is one of the most important processing part of pizza production. ZLINE’s belt proffer is with humidification and heating function or without ( as a rest station). Proffer size is designed as per the proofing time request. -
Tunnel oven
With the combination of tunnel oven and pizza base forming line, the whole automation is 100% to save work labor, improve the production capacity and final product quality. Baking time and temperature is adjustable on the control system. -
Cooling tower
Spiral cooling tower is offered based on cooling time requirement and with less space needed. The standard tower width is 900mm.
